MAINS 360-0-50-360 V at 300 mA
6.3 V CT@ 4.5 A, 6.3 V CT@ 4.5 A, 5V @ 3A. 120+120 V primary. Style "T" .

OUTPUT 6600 43% taps to 16/8/4 ohms Style "T" or "S" on request.

MAINS WW primary (100-120V) to 310-0-310 V @ 200 mA, 5 V @ 2 A, 6.3 V CT @ 6A. Electrostatic screen. Fits on chassis but not in the original can. You may need to make an adapter plate.

MAINS EU primary (200-250V) to 310-0-310 V @ 200 mA, 5 V @ 2 A, 6.3 V CT @ 6A. Electrostatic screen. Fits on chassis but not in the original can. You may need to make an adapter plate.

CHOKE 20H at 20 mA.  DCR 500 ohms approx. Open frame.

OUTPUT T2063 (STA15 series 2)
8K ohms 43 % taps to 16/8/3 ohms. 15 W at 20 Hz

OUTPUT T2142 (STA15 series 3)
7.5K ohms 43 % taps to 16/8/4 ohms. 25 W at 20 Hz

OUTPUT T2075 (STA25 series 3&4)
5K ohms 43 % taps to 16/8/4 ohms. 25 W at 20 Hz

CHOKE T2165 (STA25) 3 H 250 mA 18 ohms

CHOKE T2072 (STA15) 10H 250 mA 67 ohms Open frame

MAINS T2064 (STA15)
0 10 210 230 250 V to 350-0-350 250 mA, 6.3 V CT @ 4 A, 6.3 V CT @ 4 A, 5 V  @ 2 A Fully shrouded

MAINS T2093 (STA25)
2 x 110 120V to 350 V @ 400 mA,  120V @ 50 mA,  6.3 V CT @ 4 A,  6.3 V CT @ 4 A,  6.3 V @ 2 A  Fully shrouded

OUTPUT 6600 to 16/8/4 ohms. 100 W. Separate 43% UL winding

OUTPUT 6600 Ohms. 40W at 20 Hz

OUTPUT 8000 Ohms 30W at 15 Hz

OUTPUT 10K to 16/8/4 ohms. (Our own optimised design)

MAINS EU primary. 425-0-424 at 180 mA.
5V at 3A. 6.3V CT at 4A.

CHOKE 30 H 40 mA

CHOKE 10 H 200 mA

OUTPUT T1 4500 ohms, 100W at 25 Hz

Choke L1 5 H at 400 mA

Choke L2 20 H at 50 mA

MAINS T2 650-0-650 at 325 mA, 6.3 V CT at 5 A, 4 V at 7 A, 75 V at 10 mA
