VARIOUS

9790 Power amp/100V line monitor feed

9790 Power amp/100V line monitor feed

Provides a balanced, isolated 0 dBu 600 line feed from a power amplifier or 100V line. Input can be configured for 50/100/200/500 watt amplifiers or from a 100V line. May be loaded with a balanced or unbalanced input of 600 ohms or higher.

Price: 61.04 (Excluding VAT at 20%)

4243  DI Box transformer 10:1

4243 DI Box transformer 10:1

For connecting high impedance device such as a guitar pick-up to amplifier. Ensures that pick-up sees a high impedance load and provide hum/buzz isolation. Enables long leads from Guitar to be used without loss of signal quality. Can connect to balanced or unbalanced inputs. +34 dBu

Price: 57.51 (Excluding VAT at 20%)

Package Options

Data sheet

8044  DI Box transformer  12:1

8044 DI Box transformer 12:1

For connecting high impedance device such as a guitar pick-up to amplifier. Ensures that pick-up sees a high impedance load. Has twin electrostatic shields for improved hum/buzz isolation. Enables long leads from Guitar to be used without loss of signal quality. Can connect to balanced or unbalanced inputs +29 dBu. SIZE D DIMENSIONS

Price: 49.18 (Excluding VAT at 20%)

Package Options

Data sheet

8321  Hybrid transformer 1+1 : 1.4 CT

8321 Hybrid transformer 1+1 : 1.4 CT

Using 2 transformers a 4-wire communication system may be operated over 2 wires. Suitable for good quality speech. +10 dBu. SIZE D DIMENSIONS

Price: 49.35 (Excluding VAT at 20%)

Data sheet

8356  Hybrid transformer 1+1 : 1.4 CT

8356 Hybrid transformer 1+1 : 1.4 CT

Using 2 transformers a 4-wire communication system may be operated over 2 wires. Suitable for good quality speech. +15 dBu

Price: 57.51 (Excluding VAT at 20%)

Data sheet

8379  Mid-Side Microphone Decoder 1+1:2ct

8379 Mid-Side Microphone Decoder 1+1:2ct

Using 4 transformers provides stereo Mid and Side outputs from two microphones. Passes phantom power to microphones. +7 dBu

Price: 43.56 (Excluding VAT at 20%)

Data sheet

1135  Mid-Side Microphone Decoder 1+1:2ct

1135 Mid-Side Microphone Decoder 1+1:2ct

Using 4 transformers provides stereo Mid and Side outputs from two 200 Ohm microphones. Passes phantom power to microphones. +12 dBu

Price: 59.96 (Excluding VAT at 20%)

8392  Mid-Side Decoder for Headphones

8392 Mid-Side Decoder for Headphones

This transformer provides stereo Mid and Side outputs from two monitor signals. +20 dBu

Price: 30.20 (Excluding VAT at 20%)

Package Options

Data sheet

1427 Transistor output transformer. Replacement for Triad TY-30X.

1427 Transistor output transformer. Replacement for Triad TY-30X.

Output transformer for transistor amplifier 100 Ohms to 8 Ohms tapped at 4 Ohms. Primary inductance 0.75H DCR 13 Ohms Primary and 1.0 Ohms secondary. Max input 10V at 50 Hz. Suitable for 190 tape reverb unit. Can be used with Push-Pull or Single Ended circuit (max dc 10 mA)

Price: 43.98 (Excluding VAT at 20%)

Schematic
