ATTENUATORS

9335  Attenuator 48 dB in 2 dB steps

9335 Attenuator 48 dB in 2 dB steps

A 10k/10k transformer. 10K secondary with taps from 0 to -48dB in 2 dB steps. better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads. OCC wire option

Price: 152.82 (Excluding VAT at 20%)

Wire choice

Information

1035 Attenuator with 6 dB Gain and Balance control.  48 dB in 2 dB steps plus 4 x 0.5 dB primary balance taps

1035 Attenuator with 6 dB Gain and Balance control. 48 dB in 2 dB steps plus 4 x 0.5 dB primary balance taps

A 10k/10k transformer. 10K secondary with taps from 0 to -48dB in 2 dB steps. Primary taps provided to give +6, +5.5, +5, +4,5, +4 dB gain steps for use as a stereo balance control. Ideal for passive pre-amp where some gain is required. Better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads. OCC wire option

Price: 173.97 (Excluding VAT at 20%)

Wire choice

Information

9985  Attenuator with Balance control 48 dB in 2 dB steps plus 4 x 0.5 dB primary balance taps

9985 Attenuator with Balance control 48 dB in 2 dB steps plus 4 x 0.5 dB primary balance taps

A 10k/10k transformer. 10K secondary with taps from 0 to -48dB in 2 dB steps. primary taps provided to give +2 dB in 0.5 dB steps gain for use as a stereo balance control. Better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads. OCC wire option

Price: 173.97 (Excluding VAT at 20%)

Wire choice

Information

1429 Attenuator for fine level adjustment. Plus or minus 1.3 dB in 0.1 db steps

1429 Attenuator for fine level adjustment. Plus or minus 1.3 dB in 0.1 db steps

A 600/600 attenuator with 1.3 dB in 0.1 dB steps on primary and secondary. Max level 14 dBu at 20 Hz. Total dcr lesss than 180 Ohms. Better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads.

Price: 173.97 (Excluding VAT at 20%)

Wire choice

Information

9395  Attenuator 48 dB in 2 dB steps 0/+6dB/+12dB gain taps

9395 Attenuator 48 dB in 2 dB steps 0/+6dB/+12dB gain taps

A 10k/10k transformer. 10K secondary with taps from 0 to -48dB in 2 dB steps. primary taps provided to give +6 dB or +12 dB gain. Better than 50 kHz bandwidth on all taps. Mumetal can with colour coded leads. OCC wire option

Price: 162.49 (Excluding VAT at 20%)

Wire choice

Information

9336  Attenuator 42 dB in 3 dB steps

9336 Attenuator 42 dB in 3 dB steps

A 10k/10k transformer. 10K secondary with taps from 0 to -42dB in 3 dB steps. better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads. OCC wire option

Price: 118.17 (Excluding VAT at 20%)

Wire choice

Information

9337  Attenuator 28 dB in 2 dB steps

9337 Attenuator 28 dB in 2 dB steps

A 10k/10k transformer. 10K secondary with taps from 0 to -28dB in 2 dB steps. better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads. OCC wire option

Price: 118.17 (Excluding VAT at 20%)

Wire choice

Information

9338  Balance Control 6 dB in 0.5 dB steps

9338 Balance Control 6 dB in 0.5 dB steps

A 10k/10k transformer. 10K secondary with taps from 0 to -6dB in 0.5 dB steps. better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads. OCC wire option

Price: 118.17 (Excluding VAT at 20%)

Wire choice

Information

9339 Attenuator 24 dB in 1 dB steps

9339 Attenuator 24 dB in 1 dB steps

A 10k/10k transformer. 10K secondary with taps from 0 to -24dB in 1 dB steps. better than 100 kHz bandwidth on all taps. Mumetal can with colour coded leads.

Price: 152.82 (Excluding VAT at 20%)

Wire choice

Information

9155 Fine control 2 dB steps

9155 Fine control 2 dB steps

A 10k/10k transformer with secondary taps at 2 dB intervals. Maximum attenuation -10 dB. May be used in cascade with type 9150 to give a total of 50 dB adjustment in 2 dB steps.. Mumetal can with colour coded leads.

Price: 65.21 (Excluding VAT at 20%)

9150 Coarse control 10 dB steps

9150 Coarse control 10 dB steps

A 10k/10k transformer with secondary taps at 10 bB intervals. Maximum attenuation -40 dB. May be used in cascade with type 9155 to give a total of 50 dB adjustment in 1 dB steps. Mumetal can with colour coded leads.

Price: 57.05 (Excluding VAT at 20%)

9535 Super Tweeter  Attenuator 20 dB in 2 dB steps

9535 Super Tweeter Attenuator 20 dB in 2 dB steps

A 1:1 transformer for use with 4,8,or 16 ohm treeters. Eleven secondary taps provide frequency balancing in a loudspeaker system with a bandwidth up to 100KHz. A primary tap is privided to provide a 3 dB step up. Up to 50W at 400 Hz. 100% Mumetal core for minimal distortion and 100 dB dynamic range. Solder tags.

Price: 164.75 (Excluding VAT at 20%)
