VINTAGE COMPRESSOR TRANSFORMERS J to Z

Page:   <<   <  1  2   View All (19)

8650  UA-175  Push-Pull triode to balanced line 9CT:1

8650 UA-175 Push-Pull triode to balanced line 9CT:1

15k/185 ohm output transformer for driving a balanced ohm line from push-pull 6SN7, ECC83 etc. 50% Mumetal core for high bandwidth and dynamic range, Max output level at 50 Hz +28 dBu (19 volts). Total dc resistance ref secondary 14 ohms. Colour coded leads. Pro Audio Size K. Tested with Drip Electronics UA 175b PCB .

Price: 88.33 (Excluding VAT at 20%)

Package options

Data sheet

1285  UA-176  Push-Pull triode to balanced line 9CT:1 with attenuator.

1285 UA-176 Push-Pull triode to balanced line 9CT:1 with attenuator.

15k/185 ohm output transformer for driving a balanced ohm line from push-pull 6SN7, ECC83 etc. 50% Mumetal core for high bandwidth and dynamic range, Max output level at 50 Hz +28 dBu (19 volts). Includes primary taps for UA 176. Total dc resistance ref secondary 14 ohms. Colour coded leads. Pro Audio size K
.

Price: 119.20 (Excluding VAT at 20%)

Package options

Information

1133E UA175 Interstage transformer

1133E UA175 Interstage transformer

High performance transformer for repair or reconstruction of the Universal Audio UA175a or UA175b Compressor. Radiometal (50% Nickel) transformer in Mumetal can with threaded grommet. 52.5mm x 45 mm dia. Voltage ratio 2.3:1. Impedance ratio 80k/15k. Similar to UTC A19 but with improved bandwidth. Colour coded leads. Tested with Drip Electronics PCB.

Price: 106.82 (Excluding VAT at 20%)

1449  UA 175 / Teletronix LA-2A 1968 Input transformer (Replaces 1009)  Drip Opto 4

1449 UA 175 / Teletronix LA-2A 1968 Input transformer (Replaces 1009) Drip Opto 4

600 ohm to 50K input transformer ratio 1:9.1 Bandwidth 5Hz to 30 kHz. Similar to UTC A10. Mumetal can with side entry colour coded leads Threaded Grommet (Type 1449E) or PCB pins (Type 1449C). Suitable for Drip Electronics Opto 4, Opto 5 and UA 175b PCBs.

Price: 65.10 (Excluding VAT at 20%)

Package options

1481  150+150/15K Input  Transformer for LA3A

1481 150+150/15K Input Transformer for LA3A

General purpose. Configurable as a 1:10 step-up for mic up to 200 Ohms or 1:5 for a 600 Ohm line or Mic input. High performance Suitable for Urei LA3A line input replacement for B11178. Total dc resistance 75 ohms referred to primary. Max level +12 dBu. Package options.

Price: 59.25 (Excluding VAT at 20%)

Package Options

1493  Autoformer for LA3A compressor.

1493 Autoformer for LA3A compressor.

Sowter decign for this application. Replacement for B11178. Step up ratio 1:10.

Price: 24.95 (Excluding VAT at 20%)

1505  T188 for Telefunken U73b compressor

1505 T188 for Telefunken U73b compressor

High performance transformer for repair or reconstruction of the Telefunken U73b compressor. Some would say it is the European version of the Fairchild 670. 100% Mumetal core with full geometric balance, Mumetal can with threaded grommet. 52.5mm x 45 mm dia. Impedance ratio 15K/15K with separate half primary windings and a CT secondary. Lp = 90H Rp= Rs = 200 Ohms. Colour coded leads.

Price: 106.82 (Excluding VAT at 20%)

Page:   <<   <  1  2   View All (19)
